APEX Wheels SM-10 Flow Formed Wheel | 18x10 ET30 | 5x112

The APEX Wheels SM-10 from the Evolution Line represents a precision-engineered flow formed wheel designed for applications requiring 5x112 bolt pattern compatibility, with primary development focused on Toyota Supra platforms. This 18x10 ET30 wheel addresses the demands of wide performance applications through APEX's flow formed construction process, which combines casting efficiency with enhanced strength characteristics to deliver optimal performance for track and street use.

The SM-10 achieves a weight of 20.85 lbs in the 18x10 configuration, providing unsprung weight reduction compared to factory wheels despite the aggressive 10-inch width. This weight control becomes critical at larger widths, where traditional cast construction would result in significantly heavier wheels that compromise handling dynamics and acceleration response.

The wheel utilizes flow formed construction, a manufacturing process that begins with a cast wheel blank before applying specialized forming techniques. During flow forming, the wheel barrel is spun at high speed while rollers apply controlled pressure, stretching and compressing the aluminum to create a denser grain structure. This process increases the material strength while reducing weight compared to traditional cast wheels, positioning flow formed construction between cast and forged methods in terms of both performance and cost.

The SM-10 features Profile 3 face design, providing the deep concave geometry suited for wide applications like the 10-inch width. The 66.6mm center bore specification provides precise hub-centric mounting for 5x112 applications. The 60-degree conical hardware seat ensures proper lug nut engagement and centering. APEX offers the SM-10 in multiple finish options including Anthracite, Satin Bronze, and Satin Black.

• Compatibility: Toyota Supra (primary application), 5x112 bolt pattern vehicles
• Material: Flow Formed aluminum construction
• Weight: 20.85 lbs
• Specifications: 18x10 ET30, Center bore 66.6mm, Profile 3 face
• Hardware: 60 Degree Conical seat
• Finishes: Anthracite, Satin Bronze, Satin Black
• SKU: SM101810ET30-5112-666-AN

Wheel Specifications:
