CMS Performance Bolt-In Harness Bar For C8 Corvette

This Harness Bar Fits The Following Cars:

• 2020+ Chevrolet Corvette Stingray & Z51 (C8)
• 2023+ Chevrolet Corvette Z06 (C8)
• Does Not Fit Convertible / Roadster

Click Here For Installation Instructions

The Best Harness Bar in the World for the C8 Corvette

The C8 Corvette is an incredible, affordable track-day car that easily achieves race car performance on track. Managing that kind of performance wearing nothing but the three-point seat belt is a chore and leaves a lot to be desired in terms of safety. That's where we come in with the CMS Performance C8 Corvette Harness Bar. This provides a rock-solid, high-strength bar to mount shoulder straps for a 4-, 5-, or 6-point racing harness to keep you firmly and safely in your seat.

The CMS Performance C8 Harness Bar is the strongest, most elegantly designed C8 harness bar on the market. It seamlessly integrates into your C8 interior, and we custom powder coat it whatever color you choose, including factory color-matched hues. The CMS C8 bar allows full seat travel while locating your harness shoulder belts at the proper height for maximum on-track safety and security.

Installation requires no drilling or other modification of the chassis, and only minor modification of your interior trim.

The C8 Corvette Harness Bar That's Made in America

Every CMS harness bar is handcrafted in America by master fabricators for a perfect fit, beautifully 360^o TIG welded for high strength, and fully powder-coated in our facility for a brilliant, durable finish. And there's no extra charge for custom colors. CMS operates a complete powder-coating facility to offer you color-matched Corvette factory colors¹, giving your C8 a customized look that will last.

CNC mandrel bent and fully TIG welded from premium Docol R8 Advanced High-Strength Steel (stronger than 4130 CrMo or DOM) and finished in rich powder-coat.

Complete, detailed instructions make installation pretty simple (figure about an hour if you're reasonably handy). Installation requires modifying the two lock/seat belt trim panels and the upper trim of your center console. Our installation instructions also include cutting templates should you decide to modify your existing trim.

Add Harnesses To Complete Your Safety Upgrade

Add optional four-point Schroth Profi II ASM or Sabelt Steel Series harnesses along with the CMS Performance Harness Install Kit, and you're ready to hit the track with greatly improved driver and passenger safety. These harnesses were specifically designed for use in street cars with no sub strap pass-through in the seat.

CMS Performance C8 Corvette Harness Bar Details:

• Materials: 1.50″ x .095" Docol R8 Advanced High-Strength Steel for superior safety
• Construction: Full 360^o TIG welding for ultimate strength, integrity, and beauty
• Finish: Custom-color powder coating in any color you can imagine
• Weight: 18 lbs. (8.2 kg)
• Features: Unobstructed rear view; designed, built, and finished in the USA; allows full seat travel with any seat
• Comes with all necessary hardware

¹ Note: powder coat colors are professionally matched to be as close as possible to factory paint codes. However, color-matching powder is not the same as mixing liquid paint. In a few cases, slight color variance is normal and is not perceptible with the roll bar installed inside the car.

This product is intended for off-road race track use only
